LRPT-06D500K-A High-Performance 6-DOF Motion Platform With 80°/s(1.2m/s) Ultra-Rapid Response high load hexapod

LRT high load hexapod is fast response, high precision, and it's supported by a strong and experienced technical team. We provide customers with complete one-stop solutions! Adequate supply, fast shipping, timely delivery, to provide quality products and services. Our products are through strict testing, reliable quality, welcome to consult.



• The hexapod operates under the monitoring and control system.



• The control system adopts a hierarchical control structure.



• The monitoring unit is responsible for human-machine interface interaction, accepting user operation commands. It issues control signals to the real-time control computer.





Large carrying capacity Safe and Reliable Sturdy and Durable



DOF	Range	Velocity	Acceleration
Pitch	±25°	±30°/s	±150°/s2
Roll	±25°	±30°/s	±150°/s2
Yaw	±30°	±30°/s	±150°/s2
Sway	±0.30m	0.5m/s	5m/s2
Surge	±0.30m	0.5m/s	5m/s2
Heave	±0.18m	0.5m/s	5m/s2



Unit: mm

Weight: 600kg

Color: White

Material： Aluminum alloy + Steel

Payload: 500kg

Size: 1900mm*1645mm*1010mm

Size of Payload: ≤2000mm*2000mm*800mm

Installation method： Threaded hole

Mounting Hole Distance： Customize





Power Requirements	Rated Voltage: 220V AC(Range：-10%～10%)
	Rated frequency: 50hz(Range：-5%～5%)
	Rated power: 8.6Kw
	Peak power: 12Kw
Environment Requirements	Storage environment： Temperature：-30～65℃ Humidity：5%～95% Atmospheric pressure：85～108Kpa Protection Level：IP54
	Work environment： Temperature：-20～50℃ Humidity：5%～95% Atmospheric pressure：85～108Kpa Protection Level：IP54





Intelligent software design provides a user-friendly human-machine interface, ensuring the reliability of both the system software and hardware. It enables real-time control of hexapod and continuous monitoring of system status.















Electric Cylinders, also known as electric actuators or servo electric cylinders, are precision drive devices that convert the rotary motion of an electric motor into linear motion. They integrate components such as a servo motor, drive, high-precision ball screw or planetary roller screw, and position sensor into a complete, modular linear motion unit.





The core of an electric cylinder is its "rotary-to-linear" conversion mechanism:







Compared to traditional hydraulic and pneumatic cylinders, electric cylinders offer significant advantages:



High Precision & Controllability:

Paired with a servo system, positioning accuracy can reach the micron level, enabling complex, programmable motion profiles.



High Rigidity & High Force:

Robust construction allows them to withstand high loads and deliver high output force.



High Efficiency & Energy Saving:

High energy conversion efficiency (typically over 80%) and near-zero energy consumption in standby mode, far superior to hydraulic systems.



Clean & Environmentally Friendly:

No need for hydraulic oil or compressed air, eliminating leakage risks and ensuring a clean operating environment suitable for applications with high cleanliness requirements.



Low Noise & Low Maintenance: Smooth, quiet operation; does not require regular oil or filter changes like hydraulic systems, resulting in very low maintenance costs.



Flexible Installation: Compact, modular design allows for easy integration into various automated equipment.



Intelligence & Networking: Easily connected to PLCs, industrial PCs, etc., enabling remote monitoring, fault diagnosis, and bus control (e.g., EtherCAT, PROFINET).





Due to their excellent performance, electric cylinders have become a core component in industrial automation and are widely used in:



Industrial Automation: Robot arms, assembly lines, dispensing systems, welding equipment, precision pressing.



Testing Equipment: Simulation shake tables, fatigue testers, high-precision positioning platforms (like the motion platform mentioned previously).



Aerospace: Aircraft control surface testing, hatch simulation mechanisms.



Defense: Radar pitch drive, missile erection devices.



Medical Equipment: Surgical robots, lifting and positioning of CT scanner tables, rehabilitation equipment.



Special Vehicles: Electric vehicle battery pack testing, driving simulators.





Characteristic	Electric Cylinder	Hydraulic Cylinder	Pneumatic Cylinder
Precision	Very High	Medium	Low
Controllability	Excellent	Good	Fair
Output Force	High	Very High	Relatively Low
Speed	High	Very High	Extremely High
Maintenance Cost	Low	High	Medium
Cleanliness	Clean	Risk of Oil Contamination	Requires Filtered Air
Energy Consumption	High Efficiency & Energy Saving	Lower Efficiency	Low Efficiency
Cost	Higher Initial Investment	Complex System, Potentially Higher Total Cost	Low Initial Investment
